Chip on Board & High Power LEDs
Chip on Board & High Power LEDs
Arhat Semiconductors provides high-quality Chip on Board & High Power LEDs with superior performance and reliability. Our extensive product range includes energy-efficient lighting solutions for various applications. We prioritize innovation and precision to meet industry standards. Partner with us for top-tier LED solutions tailored to your needs.
Chip on board - Upto 180 LM/W
Packages available in 3W and 108W. CRI-80
Application: Hospitality, Museum, Architectural
& Track Lighting
EVERGLOW COB SPECIFICATION
| Sr No | Part No. | Power | Size(mm) | VF | IF | Flux | LES | CCT |
|---|---|---|---|---|---|---|---|---|
| 1 | EG1311-03XX-L140-XXX | 3W | 13.5*13.5*11 | 9-11V | 300mA | 130-140 | 11 | 2700-6000K |
| 2 | EG1311-05XX-L140-XXX | 5W | 13.5*13.5*11 | 15-17V | 300mA | 130-140 | 11 | 2700-6000K |
| 3 | EG1307-07XX-L140-XXX | 7W | 13.5*13.5*0.7 | 21-23V | 300mA | 130-140 | 7 | 2700-6000K |
| 4 | EG1311-10XX-L140-XXX | 10W | 13.5*13.5*11 | 21-23V | 300mA | 130-140 | 11 | 2700-6000K |
| 5 | EG1311-12XX-L140-XXX | 12W | 13.5*13.5*11 | 36-40V | 300mA | 130-140 | 11 | 2700-6000K |
| 6 | EG1311-15XX-L140-XXX | 15W | 13.5*13.5*11 | 54-57V | 300mA | 130-140 | 11 | 2700-6000K |
| 7 | EG1311-18XX-L140-XXX | 18W | 13.5*13.5*11 | 54-57V | 300mA | 130-140 | 11 | 2700-6000K |
| 8 | EG1917-18XX-L140-XXX | 18W | 19*19*17 | 54-57V | 300mA | 130-140 | 17 | 2700-6000K |
| 9 | EG1917-24XX-L140-XXX | 24W | 19*19*17 | 36-40V | 600mA | 130-140 | 17 | 2700-6000K |
| 10 | EG1917-30XX-L140-XXX | 30W | 19*19*17 | 36-38V | 750mA | 130-140 | 17 | 2700-6000K |
| 11 | EG2824-50XX-L140-XXX | 50W | 28*28*24 | 36-38V | 1500mA | 130-140 | 24 | 2700-6000K |
| 12 | EG1917-60XX-L140-XXX | 60W | 19*19*17 | 35-38V | 1600mA | 130-140 | 17 | 2700-6000K |
| 13 | EG2824-108XX-L140-XXX | 108W | 28*28*24 | 54-60V | 1800mA | 130-140 | 24 | 2700-6000K |
Tunable COB - Upto 165 LM/W
Packages available in 3W and 108W
Application: Commercial, Outdoor, Architectural,
Signage & Industrial Lighting
Tunable COB
| Sr No | Part No. | Power | Size(mm) | VF | IF | Flux | LES | CCT |
|---|---|---|---|---|---|---|---|---|
| 1 | EG1311-03Tunable | 3W | 13.5*13.5*11 | 9 - 11V | 300mA | 130-140 | 11 | 2700-6000K |
| 2 | EG1311-07Tunable | 7W | 13.5*13.5*11 | 15 - 17V | 300mA | 130-140 | 11 | 2700-6000K |
| 3 | EG1307-07Tunable | 9W | 13.5*13.5*0.7 | 35-39V | 200-250mA | 130-140 | 7 | 2700-6000K |
| 4 | EG1311-12Tunable | 12W | 13.5*13.5*11 | 21-23V | 300mA | 130-140 | 11 | 2700-6000K |
| 5 | EG1311-18Tunable | 18W | 13.5*13.5*11 | 36-40V | 300mA | 130-140 | 11 | 2700-6000K |
| 6 | EG1917-30Tunable | 30W | 19*19*17 | 36-40V | 750mA | 130-140 | 17 | 2700-6000K |
- Residential Lighting
- Commercial Lighting
- Outdoor Lighting
- Automotive Lighting
